Steel Structure Mezzanine

Lub Mezzanine Steel Structure Mezzanine yog ib qho kev sib xyaw ua ke hauv ib lub tsev, feem ntau yog siv los paub txog peb-dimensional spatial design. Nws pab kev cob qhia, platforms thiab lwm qhov chaw uas xav tau kev ua haujlwm peb-seem kom ua tiav qhov chaw faib thiab nthuav dav. EIHE Steel Structure (EHSS) yog lub teb chaws high-tech enterprise nrog kev paub dav hauv cov qauv hlau thiab cov chaw tsim khoom muaj zog steel qauv.

Xa lus nug

Product Description

EHSS yog lub chaw tsim khoom muaj peev xwm ua haujlwm siab. Steel Structure Mezzanine yog ib qho ntawm peb cov khoom tsim steel, uas txhim kho lub tsev ua haujlwm yam tsis muaj kev hloov pauv cov qauv hauv tsev loj. Nws ua kom sai, tsis tshua muaj nqi thiab kev kho dua tshiab ntawm lub tsev qhov chaw, thiab ua kom qhov chaw ua haujlwm ntawm thawj lub tsev.

Daim ntawv thov

Steel Structure Mezzanine tuaj yeem siv rau hauv ntau qhov xwm txheej, ntawm peb lub Hoobkas cov khoom lag luam nrov tshaj plaws hauv kev lag luam thiab kev lag luam.

✔ Warehouse Mezzanine: Warehouses, logistics centers, spare parts warehouses.

✔ Chaw Ua Haujlwm Mezzanine: Rhiav chaw ua haujlwm, chaw ua yeeb yam hauv chaw ua haujlwm.

✔ Ntau Lawm Mezzanine: Nyob ib sab ntawm cov kab sib dhos, cov khoom siv ua haujlwm.

✔ Kev Lag Luam Mezzanine: Cov khw muag khoom, chaw ua yeeb yam, khw muag khoom.

✔ Khoom siv Mezzanine: chav cua txias, khoom siv platforms.

Steel Structure Mezzanine

Qauv

Ib qho Steel Structure Mezzanine feem ntau suav nrog:

Nto System	Patterned steel phaj / steel grating / composite pem teb slab
Secondary Beam System	Channel steel / C-section steel
Main Beam System	H-nqaj / I-beam
Kum System	H-beam / ncig steel raj
railing	Daim tiab board
Staircase	Channel steel beam + kauj ruam phaj
Foundation	Lub hauv paus cais
Kev sib txuas	Chemical thauj tog rau nkoj ntsia liaj qhov rooj / cog rebar

Daim Ntawv Qhia Ceev rau Koj Cov Qauv Hlau Mezzanine Xaiv

Kev siv yuav tsum tau	Cov lus pom zoo
Lub teeb-ua haujlwm Warehouse	Independent Kem + H-beam Main Beams + Channel Steel Secondary Beams + Steel Grating Surface
Medium-duty Warehousing	Independent Kem + H-beam Main Beams + Channel Steel Secondary Beams + Patterned Steel Phaj
Hnyav Warehousing	Independent Kem + Loj H-beams + Profiled Steel Phaj Composite Floor + Ramp
Rhiav Chaw Ua Haujlwm	Txuas nrog Cov Qauv Tseem Ceeb + Composite Pem Teb + Pem Teb / Pem Teb Vuas + iav Partitions
Cov cuab yeej ua haujlwm Platform	Kev cai-tsim raws li Cov Khoom Siv Thauj Khoom + Patterned Steel Phaj + Lub Zog Muaj Zog Railings
Kev lag luam / Exhibition Hall Mezzanine	Aesthetic Design + Composite Floor + Decorative Surface + Glass Railings

Peb Qhov Zoo

Tag nrho cov txheej txheem kev tswj hwm zoo rau koj Cov Qauv Hlau Mezzanine

Txheej txheem	Kev Tswj Xyuas Zoo
Tsim	BIM + Peb-theem Review
Kev xaiv khoom	Lub teb chaws Standard Q355B / Q235B + Zoo-paub Hom
Kev ua haujlwm	Cov cuab yeej siv siab tshaj + 100% Ultrasonic kuaj
Kev kho saum npoo	Sandblasting Derusting ntawm Sa2.5 Qib, Epoxy Zinc-nplua nuj Primer + Intermediate Coat + Top Coat
Kev tshuaj xyuas ua ntej xa khoom	100% Kev soj ntsuam ntawm cov khoom Dimensions, Drilling Position, Weld Appearance thiab Xim Zaj Duab Xis Thickness
Kev teeb tsa	Cov duab kos duab nthuav dav + Kev taw qhia rau ntawm qhov chaw

Lub Sijhawm Ua Haujlwm luv

Kev tsim kho Foundation	Main Structure	Lub hnab ntawv System	Lub Sijhawm Tsim Kho Tag Nrho
Synchronized nrog ntau lawm	20-30 hnub	10-15 hnub	2-3 lub hlis

Steel Structure Mezzanine

Peb tsis muab "tus nqi qis tshaj", tab sis lav qhov "zoo tshaj tus nqi-kev ua tau zoo" kom txo tau koj cov nqi tag nrho ntawm lub neej. Nrog peb cov qauv hlau mezzanine, peb cog lus ntev rau koj:

✔ 50 xyoo kev pab cuam lub neej

✔ Kev pab txhawb nqa lub neej

✔ Kev mus saib xyuas tsis tu ncua

✔ Teb ceev ceev

✔ Tsis muaj kev txhawj xeeb tom qab kev muag khoom
