Steel Kev Kho Mob Pov Hwm Pov Hwm Tsev

EIHE Steel Structure (EHSS) tau ua lub Tsev Kho Mob Cov Khoom Siv Hluav Taws Xob Hluav Taws Xob rau cov tsev pej xeem. Nws yog cov qauv hlau ntawm lub tsev kho mob uas siv rau kev kho mob hauv nruab nrab, kev khaws cia ib ntus thiab pov tseg cov pov tseg kev kho mob, ua raws li lub teb chaws tshwj xeeb rau kev noj qab haus huv, kev tiv thaiv ib puag ncig thiab kev nyab xeeb. Peb lub Hoobkas cultivates nyob rau hauv no steel qauv kev lag luam rau ntau tshaj 20 xyoo, thiab yog dav qhuas los ntawm peb cov neeg.

Xa lus nug

Product Description

Lub Tsev Kho Mob Cov Khoom Siv Hluav Taws Xob Hluav Taws Xob yog cov qauv tshwj xeeb nrog cov txheej txheem steel, siv rau kev khaws cia ib ntus, hloov chaw lossis chaw pov tseg ntawm kev kho mob pov tseg. Nws ua lub luag haujlwm tseem ceeb hauv kev tiv thaiv kev noj qab haus huv pov tseg thiab tiv thaiv kev nyab xeeb ntawm cov neeg ua haujlwm kho mob, cov neeg mob thiab ib puag ncig. Peb cov khoom siv feem ntau siv hauv cov chaw kho mob pov tseg hauv tsev kho mob, chaw kho mob hauv cheeb tsam pov tseg cov chaw pov tseg, cov chaw ua si pov tseg pov tseg thiab lwm qhov chaw uas xav tau kev kho mob hauv nruab nrab ntawm cov pov tseg.

Cov ntaub ntawv tseem ceeb ntawm cov qauv hlau

Cov kab hlau txais yuav square steel hlab tsis tsawg dua 80 × 80mm lossis H-section steel. Cov kab hluav taws xob hauv tsev txais yuav H-section steel lossis latticed steel beams. Purlins txais yuav C-section lossis Z-section steel nrog lub thickness tsis tsawg tshaj li 2.0mm. Qhov tseem ceeb los tiv thaiv corrosion muaj xws li kub-dip galvanizing thiab hnyav-duty anti-corrosion txheej.

Auxiliary Facilities:

Qhov rooj thiab qhov rais: qhov rooj ruaj ntseg, PVC-steel qhov rais

Kev xa dej thiab cov dej ntws: PPR kav dej, stainless hlau hauv pem teb tso dej, stainless hlau ntxuav tes bass

Hluav taws xob: UV teeb, cua kiv cua, keyboards, txuag hluav taws xob, khoom siv hluav taws xob tawg

Lub hnab ntawv System

Yam khoom	Khoom siv	Specification
Phab ntsa	Pob zeb wool fireproof sandwich vaj huam sib luag	Vaj huam sib luag thickness ≥75mm, steel ntawv thickness ≥0.4mm, anti-corrosion steel ntawv
Rooj	Pob zeb wool fireproof sandwich vaj huam sib luag	Vaj huam sib luag thickness ≥75mm, waterproof thiab corrosion-resistant
Pem teb	Hlau phaj + yas	Hlau phaj thickness ≥0.3mm, tsa los ntawm 30cm, nrog paj sawv ntsug, tsis muaj dej thiab tiv thaiv dej

Functional Layout:

Tau Txais Thaj Chaw: Tshem tawm, txheeb xyuas thiab ntsuas cov khoom pov tseg kho mob

Qhov chaw cia ib ntus: Soj ntsuam khaws cov pov tseg kho mob

Disinfection Area: Disinfection ntawm cov chaw thiab tu cov cuab yeej

Chaw Ua Haujlwm & Chaw Pabcuam: Chav sau npe, chaw ua haujlwm, tsev khaws khoom, chav cuab yeej

Kev Thauj Mus Los: Ramp lossis nplooj siab rau kev nkag tau yooj yim ntawm cov tsheb thauj khoom pov tseg kho mob

Cov Kev Cai Tshwj Xeeb

Kev Tiv Thaiv Kev Tiv Thaiv Kev Tiv Thaiv: Hauv pem teb yuav tsum tsis muaj dej tsis muaj dej thiab tiv thaiv kev tawm tsam nrog kev tsim tsa.

Ramp Kev Pab: Ramps yuav tsum muaj rau kev nkag tau yooj yim ntawm cov tsheb thauj khoom pov tseg kho mob.

Kev Ceeb Toom: Cov paib ceeb toom yuav tsum raug teeb tsa raws li cov cai muaj feem xyuam.

Kev Tiv Thaiv Kev Nyab Xeeb: Kev ntsuas yuav tsum raug coj los tiv thaiv nas, yoov tshaj cum, yoov, kab laum thiab kom tsis txhob kis tus menyuam.

Technical Specifications

Lub Tsev Kho Mob Cov Khoom Siv Hluav Taws Xob Hluav Taws Xob yog cov qauv tshwj xeeb uas muaj kev phom sij ntau. Nws tau raug tsim thiab tsim ua raws li qhov koj xav tau thiab cov qauv hauv zos.

Technical Parameters	Qhov taw qhia tseem ceeb
Hom	EIHE
Khoom	Steel Kev Kho Mob Pov Hwm Pov Hwm Tsev
Tsim kev pabcuam lub neej	≥10 xyoo
Lub Tsev Loj	Tshaj 1680 ㎡
Tsev Qhov siab	16-17 m
Main qauv hlau	≥80 × 80 hli galvanized square tube
Enclosure panels	≥75 hli tuab pob zeb wool fireproof board, nrog hlau ntawv thickness ≥ 0.4 hli
Kev xav hauv av	Leak-proof, corrosion-resistant, nruab nrog kev hloov pauv thiab cov khoom pov tseg cov chaw nres nkoj.
Phab ntsa Kev kho mob	1.0 m siab anti-seepage kho
Daim ntawv tsim tsev	Npog tag nrho, me ntsis tsis zoo siab tsim.
Qhov cua tshuab	Mechanical forced ventilation + thaum muaj xwm txheej ceev
Cia kub	Qhov kub thiab txias: ≤24 teev; Lub tub yees: 3-7 ℃, ≤ 72 teev
Teeb pom kev zoo	Cov teeb hluav taws xob tawg thiab cov chaw teeb pom kev nyab xeeb
Disinfection ntaus ntawv	UV teeb / tsis siv neeg tua kab mob
Saib xyuas qhov system	Kev soj ntsuam video, lub sijhawm cia ≥ 1 xyoo
Kev xa dej thiab kev tso dej	PPR kav dej, stainless hlau pem teb tso dej, ntxuav tes bass
Kev tiv thaiv	Leak-proof, nas-pov thawj, yoov tshaj cum thiab ya-pov thawj, kab laum-pov thawj, tiv thaiv tub sab.
Zuag qhia tag nrho warranty	≥ 3 xyoos

Daim ntawv pov thawj

Peb Lub Tsev Kho Mob Cov Khoom Siv Hluav Taws Xob Hluav Taws Xob tau lees paub los ntawm cov ntawv pov thawj zoo li AISC Certification (American Standard), ISO 3834 Welding Quality Management System Certification, thiab EN1090 Certification (European Standard).
