Hlau Ncej Chaw Nres Nkoj Hlau Tsim

Steel ncej Chaw nres tsheb Steel Kev tsim kho tau txais ntau txheej txheej txheej txheej tsim los ntawm kev sib txuas ntawm cov kab hlau thiab cov kab hlau hlau ua cov pob txha pob txha loj, ua cov kev daws teeb meem niaj hnub rau cov tsev tsheb ciav hlau. Cov khoom tsim los ntawm EIHE Steel Structure (EHSS) ua ke zoo thiab ua haujlwm zoo. Raws li cov khoom lag luam zoo ntawm steel-structured chaw nres tsheb cov tsev, peb tuaj yeem xa cov chaw nres tsheb siab uas ua tau raws li koj xav tau.

Xa lus nug

Product Description

Steel ncej Chaw nres tsheb Steel Kev tsim kho siv steel ncej qauv raws li lub ntsiab load-bearing qauv ntawm chaw nres tsheb cov tsev, thiab txais ib lub Hoobkas-prefabricated thiab on-site-assembled siv hom rau kev tsim kho sai.

Steel ncej qauv yog hais txog ib tug spatial kev nyuaj siab system tsim los ntawm kev sib txuas steel kem thiab steel beams los ntawm nruj los yog semi-rigid pob qij txha. Cov qauv no ua rau cov nqaj-kem pob qij txha txhawm rau hloov khoov lub sijhawm thiab ua kom muaj txiaj ntsig zoo rau lub zog tiv thaiv kab mob, uas feem ntau siv rau ntau lub tsev.

Piv nrog rau lwm cov txheej txheem, peb cov khoom siv steel thav duab qauv muaj qee qhov zoo sib piv.

Cov khoom sib piv	Hlau Frame Qauv	Portal Frame Qauv	Reinforced Concrete Frame
Siv Pem Teb	Ntau zaj dab neeg	Ib zaj dab neeg	Ntau zaj dab neeg
Span Peev	8-15 m	12-36 m	6-12 m
Kev tsim kho ceev	Ceev ceev	Ceev tshaj	qeeb
Seismic Performance	Zoo heev	Zoo heev	Ib txwm
Spatial Flexibility	Siab	Siab tshaj	Nruab nrab
Tus nqi tag nrho	Nruab nrab-siab	Nruab nrab	Nruab nrab-qis
Siv tau Chaw Nres Tsheb Scenarios	Chaw nres tsheb Complexes, Elevated chaw nres tsheb	Canopies, Rolling Tshuag Yards	Chaw nres tsheb me me

Tsis tas li ntawd, cov qauv sib txawv raug xaiv raws li qhov sib txawv ntawm qhov yuav tsum tau ua. Qee zaum cov qauv sib txawv tuaj yeem ua ke raws li kev tsim qauv los txhim kho cov qauv kev ua haujlwm. Tib yam siv rau peb cov khoom.

Qhov xav tau ntawm qhov project	Cov qauv siv tau
Multi-story chaw nres tsheb cov tsev nrog complex functions	Hlau ncej
Loj-span-dawb qhov chaw	Portal ncej / Grid qauv
Tight kev tsim kho lub sijhawm yuav tsum tau ua tiav sai	Hlau ncej / Portal ncej
High-intensity seismic zones	Steel qauv
Ua ntej rau cov txiaj ntsig zoo	Hlau-pob zeb sib xyaw ncej

Steel thav duab kuj muaj cov kab ke sib txawv, thiab peb cov khoom siv steel ncej steel siv cov khoom siv tsis yog ib qho khoom siv. Lub ntsiab steel ncej structural systems yog raws li nram no:

System Hom	Siv tau Scenarios
Pure Steel Ncej System	Ntau qhov chaw nres tsheb
Frame-Brace System	High-seismic-siv cheeb tsam, high-rise chaw nres tsheb vaj tse
Qhob-Filled Steel Tube Kem Ncej	High bearing peev xwm yuav tsum tau, loj spans
Steel-Concrete Composite Ncej	Cov txiaj ntsig zoo tshaj plaws
Prefabricated Steel Ncej	Kev tsim kho sai, kev tsim kho ntsuab

Tsis tas li ntawd, cov khoom tseem ceeb ntawm steel ncej, los yog cov khoom tseem ceeb thiab cov ntawv thov tseem ceeb ntawm peb cov khoom, yog raws li hauv qab no:

Qeb yam khoom	Lub Npe Lub Npe	Common Specifications / Khoom siv
Vertical Load-Bearing	Hlau Kem	H-section steel kem, kem-zoo li tus, pob zeb-filled steel raj kem
Kab rov tav Load-bearing	Hlau Beam	H-section steel beam, composite beam
Lateral Force-tiv taus	Brace	Concentric brace / eccentric brace
Sib koom	Beam-Kem Joint	Bolt-weld hybrid kev twb kev txuas, tag nrho-welded kev twb kev txuas
Pem Teb Slab	Composite Pem Teb Slab	Steel bar truss lawj + cam khwb cia hauv qhov chaw pob zeb
Foundation	Kum Base	Rigid kem puag
Hom ntawv thov		Daim Ntawv Qauv
Comprehensive Transportation Hub		Qhob-filled Steel Tube Kem + Composite Beam Ncej
Chaw nres tsheb siab		Prefabricated Steel Ncej
Metro-Property Integrated Development		Frame-Brace System
Chaw Nres Tsheb Kev nthuav dav & kho dua tshiab		Hlau Ncej + Cov qauv uas twb muaj lawm

Certification thiab Quality Assurance

Cov khoom tsim los ntawmEHSSUa raws li cov qauv thoob ntiaj teb cov qauv tseem ceeb thiab raug muag dav hauv tsev thiab txawv teb chaws. Txog rau tam sim no, peb tau koom tes nrog ntau dua 500 cov neeg siv khoom thoob ntiaj teb.

Peb Cov Hlau Ncej Chaw Nres Nkoj Steel Kev tsim kho muaj kev paub zoo tshaj plaws thiab kev ua haujlwm dav dav. Lub tuam txhab tseem ceeb heev rau kev txhim kho txuj ci, nrog rau cov neeg ua haujlwm tshaj lij suav nrog ntau dua 60% ntawm peb cov neeg ua haujlwm.

Peb pheej txhim kho peb tus kheej kom xa cov khoom txaus siab tshaj plaws rau koj.

● Class-A Manufacturing Qualification

Class-A Manufacturing Qualification

● Class-A Design Qualification

Class-A Design Qualification

● Class-A Kev Tsim Nyog Tsim Nyog

Class-A Construction Qualification

Peb cov haujlwm txawv teb chaws feem ntau muab faib ua kev lag luam thiab kev tsim kho engineering. Yuav kom ua tau raws li qhov xav tau ntawm kev lag luam txawv teb chaws, peb cov khoom siv steel ncej Steel Siv cov khoom siv kuj tau txaiscov ntawv pov thawj thoob ntiaj teb, suav nrog cov qauv European, Asmeskas cov qauv thiab ISO daim ntawv pov thawj.

● American Standard thiab European Standard Certifications

American Standard and European Standard Certifications

● ISO 3834 Vuam Certification

ISO 3834 Welding Certification

● ISO Peb Daim Ntawv Pov Thawj Loj

ISO Three Major System Certifications
