Portal Ncej Steel Warehouse Siv

EIHE Steel Structure yog ib tus neeg muag khoom hauv Suav teb thiab cov chaw tsim khoom ntawm Portal Ncej Steel Warehouse Siv Cov tsev no feem ntau xav tau qhov loj-ntev, kab-dawb qhov chaw thiab hloov tau yooj yim. Portal thav duab tuaj yeem ua tau raws li qhov xav tau ntawm qhov chaw thiab kev ruaj ntseg ntawm warehouses, thiab expansion interfaces tuaj yeem khaws cia ntawm ob qho kawg ntawm cov qauv kom hloov mus rau kev hloov pauv hauv kev lag luam txhua lub sijhawm.

Xa lus nug

Product Description

Lub Portal Ncej Steel Warehouse Kev Tsim Kho yog ib qho ntawm cov khoom siv ntau tshaj plaws thiab kev tsim khoom tsim khoom. Nws lub luag haujlwm tseem ceeb yog khaws cov khoom lag luam thiab ua kom nrawm nrawm ntawm cov khoom. Peb yog cov chaw tsim khoom hauv Suav teb thiab cov chaw tsim khoom ntawm steel qauv warehouse tsev. Peb cov txheej txheem steel ua cov nroj tsuag ua raws li cov ntaub ntawv pov thawj thoob ntiaj teb thiab tau muab cov kev daws teeb meem rau ntau tus tswv hauv lub teb chaws thiab cheeb tsam thoob ntiaj teb.

Cov yam ntxwv ntawm cov khoom

Cov txheej txheem txheej txheem ntawm Portal Ncej Steel Warehouse Siv feem ntau muaj peb ntu:

● Main load-bearing Cheebtsam

Cov no yog tsim los ntawm steel kem thiab steel kab pheeb ces kaum, ua ib tug interlocking steel ncej. Cov kab hlau thiab kab teeb yog txuas nrog bolts.

● Kev them nyiaj yug system

Cov txheej txheem kev txhawb nqa feem ntau suav nrog cov hlua khi, kab rov tav kev txhawb nqa, sab-rau-kem kev txhawb nqa, kaum braces, thiab lwm yam. Lawv txoj haujlwm yog los tiv thaiv cua loads thiab av qeeg, kom ntseeg tau tias lub tsev tsis deform.

● Enclosure qauv

Cov txheej txheem enclosure hais txog cov panels npog tag nrho cov ncej steel, nrog rau cov phab ntsa panels thiab ru tsev panels. Lawv lub luag haujlwm yog muab rwb thaiv tsev thiab txuag hluav taws xob.

Kev kwv yees ntawm kev siv steel rau ntau qhov xwm txheej

Portal Ncej Steel Warehouse Siv cov xwm txheej	Tsim nyog kab sib nrug	Kev siv steel ntau (kg / m²)
Tsis muaj crane	7.5m ~ 9.0m	25-32 : kuv
Nruab nrog 5t - 10t ib leeg-girder hoist	7.5m ~ 9.0m	35-45 : kuv
Nruab nrog 16t - 20t hnyav-duty hoist	6.0m ~ 7.5m	50 ~ 65
Nyob rau hauv cov ntug dej hiav txwv typhoon (cua siab ≥ 0.7kN / ㎡)	6.0m ~ 7.5m	Raws li cov saum toj no, nce 15% mus rau 20%

Dab tsi yog nws daim ntawv thov scenarios?

Lub Portal Ncej Steel Warehouse Siv, sib nrug los ntawm cov khoom siv hauv tsev, kuj tau siv dav hauv:

● Logistics sorting centers

● Cov khw loj loj

● Aircraft hangars

● Industrial factories

● Coal sheds

Peb cov kev pabcuam

● Tsim, tsim khoom thiab kev tsim kho kev cog lus dav dav

● Muab cov ntaub ntawv pov thawj zoo

● Ua ntau lawm raws li hauv zos Portal Ncej Steel Warehouse Siv cov qauv ntawm cov neeg siv khoom

● Txhim kho kev tsim kho kom zoo, tsis muaj kev cuam tshuam rau kev nyab xeeb, txhim kho cov qauv tsim kom zoo kom txo tau kev siv steel thiab txuag nqi rau cov neeg siv khoom.

FAQ

1. Qhov zoo ntawm Portal Ncej Steel Warehouse Kev Tsim Kho yog dab tsi?

● Tus nqi qis, siv hlau tsawg dua

● Kev tsim kho ceev ceev

● Tsis tshua muaj scalable

2. Dab tsi yog qhov siab tshaj plaws rau lub qhov rooj ncej?

● Warehouse tsis muaj crane

Economic ncua: 18 - 30m

Specification qhov siab tshaj plaws: 48m

● Hoobkas nrog choj crane

Pa: ≤ 24m. Qhov siab tshaj plaws yuav tsum tsis pub tshaj 30m.

3. Puas yog nws pheej yig dua los tsim nrog hlau lossis ntoo?

Thaum tsim cov tsev lag luam, tag nrho cov nqi ntawm kev siv steel qauv yog qis dua li ntawm kev siv ntoo. Qhov no yog vim hais tias cov txheej txheem steel ua tau zoo dua, kev teeb tsa nrawm nrawm dua, qhov poob qis dua, thiab nws tiv taus cua thiab av qeeg.
